    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis

    Our Products: Chassis
    SKU: CAIW-RS316-02M-S500.H
    Brand: In-Win
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    MPN: IW-RS316-02M-S500.H
    Price: $678.95
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    IN WIN IW-RS316-02M Rackmount 500W Power Supply 3U 16X3.5 Mini SAS 12G Server Chassis
    (Click to see larger image and other views)
    Previous Item Previous Item   Next Item Next Item
    Others have been interested in these additional items...
    Check the check boxes next to the additional products that you would like to add to the shopping cart, then click on the "Add to Cart" button above. A check box is not shown if a product requires that you select an option or fill out a field. () indicates a required accessory.
    28 inch Slide Rails Kit for 1U-4U Rackmount Case
    28 inch Slide Rails Kit for 1U-4U Rackmount Case
    Price $35.00
    Front Bezel for 3U 02M Model Chassis
    Front Bezel for 3U 02M Model Chassis
    Price $34.95
    Product Details
    IW-RS316-02M

    ．3U rack-mount middle depth chassis
    ．Intel new Grantley platform compliance
    ．Iron front panel with silver printing

    Specifications

    Standard EIA-RS310D
    M/B Form Factor ATX (12" x 9.6”), ATX(12” x10”), EEB(12” x 13”)
    Dimensions (D x W x H)
    w/o Front Door    		 625 x 482.6 x 131 mm (24" x 19" x 5.25")
    Drive Bay External: Slim ODD x 1, Hot-Swap 3.5" x 16 or 2.5" x 16,
    2.5" HDD Hot-Swap x 2 (Optional)
    Internal: 2.5" HDD x 4
    Power Supply Supports
    â–ª Form Factor: Single or 2U 1+1 Redundant
    â–ª Watt: Single 500W, Redundant up to 875W
    Indicator Power Status, HDD, LANs, System Fail Activity LEDs
    Front Control Panel Power Switch, ID Switch, System Reset, NMI, USB 3.0 x 2
    Backplane Mini-SAS (6Gb/s Supported) or Mini-SAS HD (12Gb/s Supported)
    or Mini-SAS HD (12Gb/s Supported with expander function)
    Cooling Fan Supports  120 x 38 mm PWM Hot-Swap Fan x 3
    60 mm PWM Rear Fan x 2 (optional)
    Expansion Slot Full Height  PCI Slot x 7
    Material Material: SGCC
    Thickness: 1.2 mm
    Rail Kit Supports 28” Ball-bearing slide rail
    Packaging Dimensions
    (D x W x H)    		 796 * 577 * 262 mm
    Shipping Info. Net Weight: 12.8 kg
    Gross Weight: 16.45 kg
